FM14C

High Performance Floor Monitor
SKU: PLU-FM14C
Plus Audio FM14C
SKU: PLU-FM14C

The FM14C is a 2-way high-performance floor monitor, ideal for demanding live sound environments, ensuring that every detail of the performance is heard clearly. It features a 14″ LF driver and a 3″ HF compression driver, both with neodymium magnets. This configuration provides a powerful low-end response and clear, articulate high frequencies. The monitor offers a consistent 80° x 80° nominal dispersion, delivering precise and even coverage on stage.

Equipped with multiple M8 rigging points and a pole mount, the FM14C allows for versatile positioning, whether on stage or in a permanent installation. Connectivity is straightforward and reliable, with 2x Neutrik NL4MP connectors and a 1+1- wiring configuration.

The FM14C’s enclosure is constructed from durable 15mm multilayer birch plywood, finished with a rugged black polyurethane paint that withstands the wear and tear of frequent use. The front of the loudspeaker cabinet is protected by a rigid steel mesh grille with an acoustically transparent cloth.

  • Components 1 x 14″ / 1 x 3″
  • Dispersion 80° x 80°
  • SPLmax 133 dB peak
  • Weight 26 kg
Frequency Response 50Hz ~ 18kHz (±3dB)
45Hz ~ 20kHz (-10dB)
Sensitivity (1W / 1m) 110dB
Nominal Impedance
Power Rating (AES) 500W
LF Driver 1 x 14″ (3″ Voice coil) Neodymuim
HF Driver 1 x 3″ / 1.4″ exit (3″ Voice coil) Neodymuim
Maximum SPL 127dB SPL (AES), 133dB Peak
Nominal Dispersion (-6dB) 80° × 80°
Rigging 6 x M8, Pole Mount
Weight 26kg
Dimensions (H x W x D) 370 x 555 x 547mm
Connectors 2x Neutrik NL4MP
Connection Method 1+1-
Enclosure 15mm Multilayer birch plywood
Finish Black polyurethane paint
Grille Black steel grille with acoustic foam
